Accurate - G87 Glass Patch Door Hardware Sets

Function

G8700ADL – ACTIVE DUMMY LOCK (Active Dummy)

• Active handles inside and out.

G8701 – DEADLOCK (Single Cylinder)

• Deadbolt by key outside, no inside operation.

G8702 – DEADLOCK (Double Cylinder)

• Deadbolt by key either side.

G8703 – DEADLOCK (Cylinder x T-turn)

• Deadbolt by key outside, thumb turn inside.

G8704 – DEADLOCK (T-turn Inside Only)

• Deadbolt by thumb turn inside only.

G8705 – DEADLOCK (ER x T-turn)

• Deadbolt by emergency release outside, thumb turn inside.

G8722 – STORE DOOR (Store Door Lock)

• Latch bolt by lever either side.

• Deadbolt by key either side.

• No emergency egress.

G8724 – DORMITORY (Dormitory/Entrance/Storeroom)

• Latch bolt by lever either side.

• Deadbolt by key outside, thumb turn inside.

• A turn of the inside lever retracts latch and deadbolt simultaneously, automatically unlocking outside lever.

G8725 – PASSAGE (Passage)

• Latch bolt by lever either side.

G8739 – PRIVACY (Privacy x ER)

• Latch bolt by lever either side.

• Deadbolt by thumb turn and optional emergency coin turn outside.

• A turn of inside lever retracts latch and deadbolt simultaneously.

G8742 – ENTRANCE (Entry/Public Restroom)

• Latch bolt by lever either side unless outside lever is locked by Master Key from inside.

• When outside lever is locked, latch bolt by key outside and lever inside.

• Auxiliary latch deadlocks latch bolt.

G8745 – CLASSROOM (Classroom)

• Latch bolt by key outside and lever either side unless outside lever is locked by key.

• Auxiliary latch deadlocks latch bolt.

G8748 – ENTRANCE (Entrance (Locked Trim)

• Latch bolt by key outside and lever either side unless outside lever is locked by toggle action stop.

• Deadbolt by key outside and turn piece inside.

• Turning inside lever retracts latch and deadbolt simultaneously.

• Outside lever remains locked until manually unlocked by toggle.

G8749 – ENTRANCE (Entrance (Unlocked Trim)

• Latch bolt by key outside and lever either side unless outside lever is locked by toggle action stop.

• Deadbolt by key outside and turn piece inside.

• Turning inside lever retracts latch and deadbolt simultaneously.

• Outside lever remains unlocked until manually locked by toggle or projection of deadbolt.

G8756 – ENTRANCE OR OFFICE (Entrance/Office)

• Latch bolt by key outside and lever either side unless outside lever is locked by toggle action stop.

• Auxiliary latch deadlocks latch bolt.

G8759 – STOREROOM (Storeroom/Closet)

• Latch bolt by lever inside and key outside.

• Outside lever always rigid.

• Auxiliary latch deadlocks latch bolt.

Ordering Guide

Glass Patch Door Hardware Sets - Glass Door Strike Sold Separately

**All trims will be pre-selected as part of the included set. For further customization options, please refer to Accurate’s website and/or Contact Us for the next steps.**

1. Choose your function: G8700ADL, G8701, G8702, G8703, G8704, G8705, G8722, G8724, G8725, G8739, G8742, G8745, G8748, G8749, G8756, G8759
   (For more info on each function please review functions)

2. Select a backset: Standard options include 2". For custom backsets, please contact us.

3. Select a finish: Standard finishes are limited. Custom finishes may incur additional cost and extended lead times.

4. Determine handing (if applicable): Refer to the handing chart for guidance.

5. Specify door thickness: Standard configuration is designed for 1/2" thick glass doors.

You may refer to the product specifications or visit Accurate’s website for more info. For additional assistance, feel free to Contact Us.
